1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions

    Buy cheap 1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions from wholesalers

    Buy cheap 1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions from wholesalers
    • Buy cheap 1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions from wholesalers
    • Buy cheap 1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions from wholesalers
    • Buy cheap 1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions from wholesalers

    1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions

    Ask Lasest Price
    Brand Name : QYT
    Model Number : PPC-J133WAC
    Certification : CE, FCC, RoHS, IP65
    Price : Negotiable
    Payment Terms : T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
    Supply Ability : 5000 Set/Sets per Month
    Delivery Time : 3-10 Business Days
    • Product Details
    • Company Profile

    1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions

    1920×1080 resolution Touch Screen HMI Computer, fanless all in one pc for industrial solutions

    Industrial All in One Touchscreen PC Feature

    1. 13.3" TFT LED, resolution 1920 x 1080, capacitive touch
    2. Intel Celeron Quad Core J1900 2.0GHz
    3. 4GB RAM, 128G SSD
    4. Ports: 1xHDMI, 4xUSB, 2xLAN, 2xCOM(RS232/422/485 freely switched)
    5. Operating System: Win7/8/10/Linux/Ubuntu
    6. DC9V~36V Input
    7. TPM2.0, Hardware Encryption
    8. -20°C~70°C Operating Temperature;

    PPC-J133WAC
    System
    CPUIntel Celeron Quad Core J1900 2.0GHz
    L2 Cache2MB
    ChipsetsIntel Bay Trail SOC
    MemoryDDR3L 1333MHz 4GB, Up to 8GB
    Harddisk1 x mSATA 64G SSD / (128G / 250G / 500G SSD) optional
    GraphicsIntel HD Graphics
    NetworkIntel® I211-AT GbE LAN
    AudioRealtek ACL662 Audio controller
    TPMTPM 2.0
    Operation SystemWindows7 / 8 / 10, Linux, Ubuntu, Debian
    I / O
    HDMI1 x H-DMI
    LAN2 x LAN
    USB3 x USB2.0 / 1 x USB3.0
    COM2 x RS-232 / 422 / 485
    Wireless Network4G / WiFi / Bluetooth ( Optional )
    Other I/O Interface1 x Power Switch
    LCD Panel
    Panel Size13.3" Led
    Resolution1920 x 1080
    Aspect Ratio16:9
    Display Brightness400 cd/m2
    Contrast Ratio900:1
    Backlight Lifetime50000 Hr (min.)
    Viewing Angle85 / 85 / 85 /85 (CR≥10) ( L / R / U / D )
    Touch screen
    Touch Screen TypeMulti-Touch PCAP
    Transmittance>90%
    Response Time<5ms
    Surface Hardness≥7H
    Supply Voltage5.0V DC
    Touch Life≧ 3000W
    Institutional
    MaterialAl-alloy Panel
    ColorGray
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP65 / IP66
    Product Dimension344.50 x 216 x 60 mm
    Cut-out Size331 x 203 mm
    Packing Size450 x 170 x 350 mm
    Gross Weight5 KG
    Power and Environment
    Operating Temperature-20~70°C
    Storage Temperature-30~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC IN 9V~36V
    Power Consumption≦30W

    1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions


    Compared with home computers, the application environment of Industrial All in one Touchscreen PC is much worse.

    What is an Industrial All in one Touchscreen PC? It is often used in control sites, road and bridge tolls, medical care, environmental protection, communications, intelligent transportation, monitoring, voice, CNC machine tools, fuel dispensers, finance, petrochemicals, geophysical exploration, military industry, electricity, railways, highways , aerospace, subway and other harsh environments.

    These industrial sites generally have strong vibration, lots of dust, and high electromagnetic interference. The outdoor environment is also accompanied by high temperature, low temperature, humidity and other characteristics, and the continuous operation of the industrial environment is almost 7*24 hours. Ordinary home computers are not up to these working requirements.


    Industrial Panel PC Features:

    Rated For Extreme Temperatures

    Intel J1900, 8th Gen Core i3/i5/i7 Processors

    Less than 2% Failure Rate

    Responsive Touch Glass

    Fanless Design & Rugged Construction


    Quality 1920×1080 Resolution Touch Screen HMI Computer Fanless All In One Pc For Industrial Solutions for sale
