    OEM Capacitive Touchscreen Display

    Ask Lasest Price
    Brand Name : QYT
    Model Number : PM-H012WAC
    Certification : CE, FCC, RoHS
    Price : Negotiable
    Payment Terms : T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
    Supply Ability : 5000 Set/Sets per Month
    Delivery Time : 3-10 Business Days
    • Product Details
    • Company Profile

    OEM Capacitive Touchscreen Display

    OEM 12 inch wall mounted sunlight readable Capacitive Touch Monitor for industrial application

    Feature

    The industrial touch monitor is ideal for applications such as monitoring equipment, supervisory controller, process control systems, CNC machinery control, numerical control device and industrial automation.

    1. 12.1" industrial touch monitor
    2. Adopt multi-touch capacitive touchscreen


    3. HDMI/VGA/DVI multiple signals input supported

    4. DC12V Input, (+9V~36V) wide voltage input optional

    5. IP65 Compliant Front Panel

    6. 1000nits, 1500nits brightness optional

    7. Embedded / VESA mounting

    8. Sturable rugged enclosure which is for harsh environment

    PM-H012WAC
    LCD PanelPanel Size12.1" Led
    Resolution1280 x 800
    Aspect Ratio16:10
    Display Brightness450 cd/m2
    Contrast Ratio700:1
    Colors16.7M , 74% NTSC
    Backlight Lifetime50000 Hr (min.)
    Viewing Angle80 / 80 / 80 / 60 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen TypeMulti-Touch PCAP
    Transmittance>90%
    Response Time<5ms
    Surface Hardness≥6H
    Supply Voltage5.0V DC
    Touch Life≧ 3000W
    I / OVGA1 x VGA
    H-DMI1 x H-DMI
    DVI1 x DVI
    USB1 x Touch USB
    Other I/O Interface1 x OSD Control Key
    InstitutionalMaterialHigh-strength Al-alloy, support IP65
    ColorGray
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP65
    Product Dimension314 x 216 x 55 mm
    Cut-out Size300 x 203 mm
    Packing Size450 x 170 x 350 mm
    Gross Weight5 KG
    Power and EnvironmentOperating Temperature-20~70°C
    Storage Temperature-30~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V / optional(+9V~36V)


    OEM Capacitive Touchscreen DisplayOEM Capacitive Touchscreen Display
    Application
    Industry 4.0
    Rail Transit
    Equipment Control Cabinet
    Industrial Equipment Control
    Cabin Driving
    Vision Detection
    CNC Control Panel

    Our Advantage

    1. Experience
    QYT has more than 10 years rich experience in Industrial Computer/monitor filed.

    2. Wide products line

    QYT possesses 5 series of industrial products, rugged and durable waterproof computer (WPC), highly integrated control HMI (DCP) and embedded fanless industrial panel computer (PPC), embedded industrial computer ( IPC) and embedded fanless industrial computers (EFIC). The product range constantly launches mainstream cost-effective products according to the market demand. Currently there are more than 200 models and other options to serve the market demand.


    3. Customization functions
    Relying on professional technical capabilities and R&D advantages, QYT creates the most competitive OEM/ODM products according to user demands and industry characteristics.

    4.Widely useage environment
    QYT pc are widely used in industrial automation, CNC machine, data acquisition, process control, motion control, automated testing, visual inspection, communication gateways and other application fields, as well as rail transit, intelligent transportation, petrochemical, electricity, new energy, medical equipment, environmental monitoring, financial self-service and other industries.
