    USB VGA 21.5" Embedded 10 Point Capacitive Touch Screen Aluminum Alloy Case

    Ask Lasest Price
    Brand Name : QYT
    Model Number : PM-H215WAC
    Certification : IP65 CE ROHS FCC
    Payment Terms : T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
    Supply Ability : 5000 Piece/Pieces per Month
    Delivery Time : 3 working days upon receive the payment
    • Product Details
    • Company Profile

    USB VGA 21.5" Embedded 10 Point Capacitive Touch Screen Aluminum Alloy Case

    21.5" Embedded Aluminum Alloy Case Capacitive Touch Monitor USB VGA


    Feature
    1. Aluminium alloy front panel, front IP65 waterproof
    2. 21.5" TFT LED, resolution 1920*1080, 10 points capacitive touch, pcap touch monitor
    3. HD-MI/VGA/DVI multiple signals input supported
    4. Embedded / VESA mounting
    5. DC12V Input, (+9V~36V) wide voltage input optional


    Specification

    PM-H215WAC
    LCD PanelPanel Size21.5" FHD LED
    Resolution1920 x 1080
    Aspect Ratio16:9
    Display Brightness250 cd/m2
    Contrast Ratio3000:1
    Colors16.7M , 74% NTSC
    Backlight Lifetime50000 Hr (min.)
    Viewing Angle89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen TypeMulti-Touch PCAP
    Transmittance>90%
    Response Time<5ms
    Surface Hardness≥6H
    Supply Voltage5.0V DC
    Touch Life≧ 3000W
    I / OVGA1 x VGA
    H-DMI1 x H-DMI
    DVI1 x DVI
    USB1 x Touch USB
    Other I/O Interface1 x OSD Control Key
    InstitutionalMaterialHigh-strength Al-alloy, support IP65
    ColorGray
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP65
    Product Dimension538 x 330 x 55 mm
    Cut-out Size520 x 312 mm
    Packing Size630 x 190 x 480 mm
    Gross Weight12 KG
    Power and EnvironmentOperating Temperature-20~70°C
    Storage Temperature-30~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V / optional(+9V~36V)

    USB VGA 21.5" Embedded 10 Point Capacitive Touch Screen Aluminum Alloy CaseUSB VGA 21.5" Embedded 10 Point Capacitive Touch Screen Aluminum Alloy Case


    USB VGA 21.5" Embedded 10 Point Capacitive Touch Screen Aluminum Alloy Case

    FAQ
    1. Q: Are you a manufacturer or trading company?
    A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
    2. Q: Do you provide ODM/OEM or customized service?
    A: Yes,we support OEM&ODM service, let you get the products you want exactly.
    3. Q: What certifications do you have?
    A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
    4. Q: How long is the warranty?
    A: Our factory promised warranty is 1 year.
    5. Q:What is the lead time?
    A: 3 business days for samples order, 15 business days for mass production.
    6. Q: What is the MOQ?
    A: Sample testing is acceptable, the price is negotiable for bulk order.
