    450nits Rugged Embedded Computer Hmi Touch Panel VESA GPIO Windows

    Ask Lasest Price
    Brand Name : QYT
    Model Number : PPC-J008SAR
    Certification : IP65 FCC CE ROHS
    Payment Terms : T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
    Supply Ability : 5000 Piece/Pieces per Month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    450nits Rugged Embedded Computer Hmi Touch Panel VESA GPIO Windows

    450nits 800 X 600 Industrial Hmi Touch Panel VESA With GPIO Windows


    Feature

    1. 8.4" TFT LED, resolution 800 x 600, resistive touch


    2. Intel Bay trail j1900 CPU: 2.0GHz, industrial computer

    3. Multi ports for option: VGA/HD-MI/LAN/USB/COM

    4. Operating System: Win7/8/10/Linux/Ubuntu

    5. DC12V~24V Input,(+9V~36V)wide voltage input optional

    Product Advantage

    1. Wide range: -20°C to 70°C working temperature range.


    2. Industrial LCD panel is wide viewing angle with high nits and true color.


    3. Motherboard is high performance and 7x24 continuous operation available.


    4. Heat sink in back case great for heat dissipation and beautiful appearance.


    5. Working voltage is wide range 12-24V, suitable for various industrial applications.


    6. Symmetric design can be utillized in portrait mode with style.


    Specification

    PPC-J008SAR
    SystemCPUIntel Celeron Quad Core J1900 2.0GHz
    L2 Cache2MB
    ChipsetsIntel Bay Trail SOC
    MemoryDDR3L 1333MHz 4GB, Up to 8GB
    Harddisk1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
    GraphicsIntel HD Graphics
    NetworkIntel 82583V 1000 Mbps port
    AudioRealtek ACL662 Audio controller
    Operation SystemWindows7 / 8 / 10, Linux, Unix, QNX
    I / OVGA1 x VGA
    Digital signal1 x HD-MI
    USB3 x USB2.0 / 1 x USB3.0
    LAN1 x LAN
    Wireless NetworkWiFi + Bluetooth ( Optional )
    Other I/O Interface1 x Power Switch
    LCD PanelPanel Size8.4" Led
    Resolution800 x 600
    Aspect Ratio4:3
    Display Brightness450 cd/m2
    Contrast Ratio600:1
    Colors262K/16.2M , 40% NTSC
    Response Time20/10 (Typ.)(Tr/Td) ms
    Viewing Angle80 / 80 / 80 / 60 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen Type5 wire resistive touch
    Transmittance>85%
    Response Time<5ms
    Surface Hardness≥3H
    Supply Voltage5.0V DC
    Touch Life≧ 1000W
    InstitutionalMaterialAluminum Alloy Panel + Sheet Metal Back Cover, Baking Varnish Treated
    ColorSilver / Black ( optional )
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP65
    Product Dimension235 x 185 x 55 mm
    Cut-out Size221 x 171 mm
    Packing Size360 x 180 x 320 mm
    Gross Weight4.0 KG
    Power and EnvironmentOperating Temperature-10~60°C
    Storage Temperature-20~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V~19V / optional(+9V~36V)
    Power Consumption≦30W

    450nits Rugged Embedded Computer Hmi Touch Panel VESA GPIO Windows

    450nits Rugged Embedded Computer Hmi Touch Panel VESA GPIO Windows450nits Rugged Embedded Computer Hmi Touch Panel VESA GPIO Windows450nits Rugged Embedded Computer Hmi Touch Panel VESA GPIO Windows


    Our Advantage

    1. Experience

    QYT has more than 10 years rich experience in Industrial Computer/monitor filed.


    2. Wide products line

    7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.


    3. Customization functions

    It offers rich of interface to meet csutomers needs.


    4.Widely useage environment

    QYT computer/monitor which is widly used for kitchen,food industry, boat...etc


    FAQ
    1. Q: Are you a manufacturer or trading company?
    A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
    2. Q: Do you provide ODM/OEM or customized service?
    A: Yes,we support OEM&ODM service, let you get the products you want exactly.
    3. Q: What certifications do you have?
    A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
    4. Q: How long is the warranty?
    A: Our factory promised warranty is 1 year.
    5. Q:What is the lead time?
    A: 3 business days for samples order, 15 business days for mass production.
    6. Q: What is the MOQ?
    A: Sample testing is acceptable, the price is negotiable for bulk order.
