    Embedded 15" Capacitive Waterproof Touch Screen Display For Cabinet

    Ask Lasest Price
    Brand Name : QYT
    Model Number : PM-H015SAC
    Certification : CE, FCC, RoHS
    Price : Negotiable
    Payment Terms : T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
    Supply Ability : 5000 Set/Sets per Month
    Delivery Time : 3-10 Business Days
    • Product Details
    • Company Profile

    Embedded 15" Capacitive Waterproof Touch Screen Display For Cabinet

    15" embedded mounting Capacitive Touch industrial Monitor high brightness for cabinet

    Feature

    The industrial touch monitor is ideal for applications such as monitoring equipment, supervisory controller, process control systems, CNC machinery control, numerical control device and industrial automation.

    1. Aluminium alloy front panel, front IP65 waterproof

    2. 15" TFT LED, resolution 1024 * 768, rugged industrial displays

    3. HD-MI/VGA/DVI multiple signals input supported

    4. Embedded / VESA mounting

    5. DC12V Input, (+9V~36V) wide voltage input optional
    PM-H015SAC
    LCD PanelPanel Size15" Led
    Resolution1024 x 768
    Aspect Ratio4:3
    Display Brightness350 cd/m2
    Contrast Ratio1000:1
    Colors16.7M , 74% NTSC
    Backlight Lifetime50000 Hr (min.)
    Viewing Angle89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen TypeMulti-Touch PCAP
    Transmittance>90%
    Response Time<5ms
    Surface Hardness≥6H
    Supply Voltage5.0V DC
    Touch Life≧ 3000W
    I / OVGA1 x VGA
    H-DMI1 x H-DMI
    DVI1 x DVI
    USB1 x Touch USB
    Other I/O Interface1 x OSD Control Key
    InstitutionalMaterialHigh-strength Al-alloy, support IP65
    ColorGray
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP65
    Product Dimension361 x 285 x 55 mm
    Cut-out Size347 x 271 mm
    Packing Size460 x 180 x 400 mm
    Gross Weight7 KG
    Power and EnvironmentOperating Temperature-20~70°C
    Storage Temperature-30~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V / optional(+9V~36V)

    Embedded 15" Capacitive Waterproof Touch Screen Display For CabinetEmbedded 15" Capacitive Waterproof Touch Screen Display For Cabinet

    Advantages

    1. Full Material is aluminium alloy, it's very sturdy and durables.


    2. Symmetric design can be utillized in portrait mode with style.


    3. Industrial LCD panel and touchscreen is industrial grade, high nits, true color and suitable for poor working enviroment


    4. Signal ports is VGA, DVI and HDMI, suitable for different applications.


    5. -20C to +70°C Wide temperature support.


    6. Accept customization


    FAQ

    1. Q: Are you a manufacturer or trading company?
    A: We're a professional manufacturer with more than 10 years experience in industrial automation field.

    2. Q: Do you provide ODM/OEM or customized service?
    A: Yes,we support OEM&ODM service, let you get the products you want exactly.

    3. Q: What certifications do you have?
    A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.

    4. Q: How long is the warranty?
    A: Our factory promised warranty is 1 year.

    5. Q:What is the lead time?
    A: 3 business days for samples order, 15 business days for mass production.

    6. Q: What is the MOQ?
    A: Sample testing is acceptable, the price is negotiable for bulk order.
