Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment

    Buy cheap Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment from wholesalers

    Buy cheap Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment from wholesalers
    • Buy cheap Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment from wholesalers
    • Buy cheap Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment from wholesalers

    Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment

    Ask Lasest Price
    Brand Name : QYT
    Model Number : WPC-J015SBR
    Certification : CE, FCC, RoHS, IP67 IP69K
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/A, D/P
    Supply Ability : 5000 Set/Sets per Month
    Delivery Time : 3-10 Business Days
    • Product Details
    • Company Profile

    Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment

    Aluminium Alloy 15" Full IP65/66/67 Waterproof PC J1900 For Humid And Watered Environment

    Feature

    The waterproof pc is ideal for applications such as marine/Sailing boat, medical equipment, humid production equipment, food Industry, chemical manufacturing and other outdoor applications.


    1. 15" TFT LED, adopt 5 wire resistive touch screen, high precision, durable, anti-interference.


    2. Intel Celeron Quad Core J1900 2.0GHz


    3. 1x DDR3L 1333MHz 4GB. Max up to 8GB


    4. Multi ports optional:HDMI/LAN/USB/COM


    5. VESA Mounting: 100 x 100 mm


    6. DC12V~24V Input (+9V~36V wide voltage optional)


    7. Wide range: -20°C to 70°C working temperature range.


    8. 1000nits sunlight readable optional

    WPC-J015SBR
    SystemCPUIntel Celeron Quad Core J1900 2.0GHz
    L2 Cache2MB
    ChipsetsIntel Bay Trail SOC
    MemoryDDR3L 1333MHz 4GB, Up to 8GB
    Harddisk1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
    GraphicsIntel HD Graphics
    NetworkIntel 82583V 1000 Mbps port
    AudioRealtek ACL662 Audio controller
    Operation SystemWindows7 / 8 / 10, Linux, Unix, QNX
    I / OVGA1 x VGA / 1 x HD-MI ( Optional )
    LAN1 x LAN ( Optional )
    USB3 x USB2.0 / 1 x USB3.0 ( Optional )
    COM2 x RS232 ( Optional )
    Wireless NetworkWiFi + Bluetooth ( Optional )
    Other I/O Interface1 x Power Switch
    LCD PanelPanel Size15" Led
    Resolution1024 x 768
    Aspect Ratio4:3
    Display Brightness350 cd/m2
    Contrast Ratio1000:1
    Colors16.7M , 72% NTSC
    Response Time30 (Typ.)(Tr+Td) ms
    Viewing Angle89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen Type5 wire resistive touch
    Transmittance>85%
    Response Time<5ms
    Surface Hardness≥3H
    Supply Voltage5.0V DC
    Touch Life≧ 1000W
    InstitutionalMaterialAluminum Alloy Shell
    ColorSilver / Black ( optional )
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP67 / IP68 / IP69K
    Product Dimension360 x 283 x 50 mm
    Cut-out Size/
    Packing Size460 x 180 x 400 mm
    Gross Weight7.0 KG
    Power and EnvironmentOperating Temperature-10~60°C
    Storage Temperature-20~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V~24V / optional(+9V~36V)
    Power Consumption≦30W



    Aluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered EnvironmentAluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered EnvironmentAluminium Alloy J1900 IP65 Waterproof Touch Screen PC For Watered Environment

    Applications


    Industrial automation


    human Machine Interface


    Marine control system


    welding industry


    supervisory control


    numerical control device


    Our Advantage


    1. Experience

    QYT has more than 10 years rich experience in Industrial Computer/monitor filed.


    2. Wide products line

    QYT possesses 5 series of industrial products, rugged and durable waterproof computer (WPC), highly integrated control HMI (DCP) and embedded fanless industrial panel computer (PPC), embedded industrial computer ( IPC) and embedded fanless industrial computers (EFIC). The product range constantly launches mainstream cost-effective products according to the market demand. Currently there are more than 200 models and other options to serve the market demand.


    3. Customization functions

    Relying on professional technical capabilities and R&D advantages, QYT creates the most competitive OEM/ODM products according to user demands and industry characteristics.


    4.Widely useage environment

    QYT pc are widely used in industrial automation, CNC machine, data acquisition, process control, motion control, automated testing, visual inspection, communication gateways and other application fields, as well as rail transit, intelligent transportation, petrochemical, electricity, new energy, medical equipment, environmental monitoring, financial self-service and other industries.
