    Outdoor Resistive Ip66 Waterproof Touch Screen PC Humid Environment Use

    Ask Lasest Price
    Brand Name : QYT
    Model Number : WPC-J012WAR
    Certification : CE, FCC, RoHS, IP68, IP69K
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/A, D/P
    Supply Ability : 5000 Set/Sets per Month
    Delivery Time : 3-7 Business Days
    • Product Details
    • Company Profile

    Outdoor Resistive Ip66 Waterproof Touch Screen PC Humid Environment Use

    Full Ip66 Waterproof Computer Outdoor Resistive Touch Screen Humid Environment CE ROHS

    Feature

    This is a Aluminum Alloy IP68 waterproof PC, fanless, strong and tightly-sealed to sustain punishing temperatures, harsh impacts and intense equipment washdowns.


    1. 12.1" TFT LED Resistive touch

    2. Intel Celeron Quad Core J1900 2.0GHz


    3. 1x DDR3L 1333MHz 4GB. Max up to 8GB


    4. Multi ports optional:HDMI/LAN/USB/COM


    5. Full system IP67/IP68/IP69K with Aluminum Alloy Shell


    6. DC12V~24V Input (+9V~36V wide voltage optional)


    7. -20°C ~ 70°C extended operating temperature

    WPC-J012WAR
    SystemCPUIntel Celeron Quad Core J1900 2.0GHz
    L2 Cache2MB
    ChipsetsIntel Bay Trail SOC
    MemoryDDR3L 1333MHz 4GB, Up to 8GB
    Harddisk1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
    GraphicsIntel HD Graphics
    NetworkIntel 82583V 1000 Mbps port
    AudioRealtek ACL662 Audio controller
    Operation SystemWindows7 / 8 / 10, Linux, Unix, QNX
    I / OVGA1 x VGA / 1 x HD-MI ( Optional )
    LAN2 x LAN ( Optional )
    USB4 x USB ( Optional )
    COM2 x RS232 ( Optional )
    Wireless NetworkWiFi + Bluetooth ( Optional )
    Other I/O Interface1 x Power Switch
    LCD PanelPanel Size12.1" Led
    Resolution1280 x 800
    Aspect Ratio16:10
    Display Brightness450 cd/m2
    Contrast Ratio700:1
    Colors16.7M , 76% NTSC
    Response Time50000 Hr (min.)
    Viewing Angle80 / 80 / 80 / 60 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen TypeResistive touch
    Transmittance>85%
    Response Time<5ms
    Surface Hardness≥3H
    Supply Voltage5.0V DC
    Touch Life≧ 1000W
    InstitutionalMaterialAluminum Alloy Shell
    ColorSilver / Black ( optional )
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP67 / IP68 / IP69K
    Product Dimension312 x 214 x 42 mm
    Cut-out Size/
    Packing Size450 x 170 x 350 mm
    Gross Weight7.0 KG
    Power and EnvironmentOperating Temperature-10~60°C
    Storage Temperature-20~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V~24V / optional(+9V~36V)
    Power Consumption≦25W

    Outdoor Resistive Ip66 Waterproof Touch Screen PC Humid Environment UseOutdoor Resistive Ip66 Waterproof Touch Screen PC Humid Environment UseOutdoor Resistive Ip66 Waterproof Touch Screen PC Humid Environment Use

    Our Advantage

    1. Experience

    QYT has more than 10 years rich experience in Industrial Computer/monitor filed.


    2. Wide products line

    7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.


    3. Customization functions

    It offers rich of interface to meet csutomers needs.


    4.Widely useage environment

    QYT computer/monitor which is widly used for kitchen,food industry, boat...etc

    Applications
    The waterproof computers are a great solution for food and beverage processing, agriculture and automation control where the computers are in constant threat of water splash from all directions to even water immersion.


    FAQ

    1. Q: Are you a manufacturer or trading company?

    A: We're a professional manufacturer with more than 10 years experience in industrial automation field.

    2. Q: Do you provide ODM/OEM or customized service?

    A: Yes,we support OEM&ODM service, let you get the products you want exactly.

    3. Q: What certifications do you have?

    A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.

    4. Q: How long is the warranty?

    A: Our factory promised warranty is 1 year.

    5. Q:What is the lead time?

    A: 3 business days for samples order, 15 business days for mass production.

    6. Q: What is the MOQ?

    A: Sample testing is acceptable, the price is negotiable for bulk order.
