Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable

    Buy cheap Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable from wholesalers

    Buy cheap Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable from wholesalers
    • Buy cheap Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable from wholesalers
    • Buy cheap Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable from wholesalers
    • Buy cheap Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable from wholesalers

    Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable

    Ask Lasest Price
    Brand Name : QYT
    Model Number : WPC-J156WBR
    Certification : CE, FCC, RoHS, IP67, IP69K
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/A, D/P
    Supply Ability : 5000 Set/Sets per Month
    Delivery Time : 3-7 Business Days
    • Product Details
    • Company Profile

    Fanless Linux Washable Waterproof Touch Screen PC Sunlight Readable

    IP65, IP66, IP67 fanless linux washable touch screen waterproof pc sunlight readable

    Feature
    The waterproof pc is ideal for applications such as marine/Sailing boat, medical equipment, humid production equipment, food Industry, chemical manufacturing and other outdoor applications.

    1.15.6" TFT LED, resolution 1920*1080, resistive touch


    2. Intel Bay trail j1900 CPU: 2.0GHz, full ip656667 outdoor waterproof industrial grade computers
    3. Multi ports for option: VGA/HD-MI/LAN/USB/COM

    4. Operating System: Win7/8/10/Linux/Ubuntu

    5. DC12V~24V Input,(+9V~36V)wide voltage input optional
    WPC-J156WBR
    SystemCPUIntel Celeron Quad Core J1900 2.0GHz
    L2 Cache2MB
    ChipsetsIntel Bay Trail SOC
    MemoryDDR3L 1333MHz 4GB, Up to 8GB
    Harddisk1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
    GraphicsIntel HD Graphics
    NetworkIntel 82583V 1000 Mbps port
    AudioRealtek ACL662 Audio controller
    Operation SystemWindows7 / 8 / 10, Linux, Unix, QNX
    I / OVGA1 x VGA / 1 x HD-MI ( Optional )
    LAN1 x LAN ( Optional )
    USB3 x USB2.0 / 1 x USB3.0 ( Optional )
    COM2 x RS232 ( Optional )
    Wireless NetworkWiFi + Bluetooth ( Optional )
    Other I/O Interface1 x Power Switch
    LCD PanelPanel Size15.6" Led
    Resolution1920 x 1080
    Aspect Ratio16:9
    Display Brightness600 cd/m2
    Contrast Ratio800:1
    Colors16.7M , 76% NTSC
    Response Time30 (Typ.)(Tr/Td) ms
    Viewing Angle80 / 80 / 80 / 65 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen Type5 wire resistive touch
    Transmittance>85%
    Response Time<5ms
    Surface Hardness≥3H
    Supply Voltage5.0V DC
    Touch Life≧ 1000W
    InstitutionalMaterialAluminum Alloy Shell
    ColorSilver / Black ( optional )
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP67 / IP68 / IP69K
    Product Dimension398 x 247 x 52 mm
    Cut-out Size/
    Packing Size460 x 180 x 400 mm
    Gross Weight7.0 KG
    Power and EnvironmentOperating Temperature-10~60°C
    Storage Temperature-20~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V~24V / optional(+9V~36V)
    Power Consumption≦30W


    Fanless Linux Washable Waterproof Touch Screen PC Sunlight ReadableFanless Linux Washable Waterproof Touch Screen PC Sunlight ReadableFanless Linux Washable Waterproof Touch Screen PC Sunlight Readable

    Packing List

    WPC-J156WBR Waterproof Panel PC

    Waterproof VGA/RS232/LAN/USB/COM cables

    1x Utility DVD Driver
    1x Power Adaptor

    Applications

    Industrial automation

    human Machine Interface

    Marine control system

    welding industry

    supervisory control

    numerical control device


    FAQ
    1. Q: Are you a manufacturer or trading company?
    A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
    2. Q: Do you provide ODM/OEM or customized service?
    A: Yes,we support OEM&ODM service, let you get the products you want exactly.
    3. Q: What certifications do you have?
    A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
    4. Q: How long is the warranty?
    A: Our factory promised warranty is 1 year.
    5. Q:What is the lead time?
    A: 3 business days for samples order, 15 business days for mass production.
    6. Q: What is the MOQ?
    A: Sample testing is acceptable, the price is negotiable for bulk order.
