    Medical Grade Desktop IP67 Panel PC Wide Touch Screen RoHS Approval

    Ask Lasest Price
    Brand Name : QYT
    Model Number : WPC-O156WBR
    Certification : CE, FCC, RoHS, IP67, IP69K
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/A, D/P
    Supply Ability : 5000 Set/Sets per Month
    Delivery Time : 3-7 Business Days
    • Product Details
    • Company Profile

    Medical Grade Desktop IP67 Panel PC Wide Touch Screen RoHS Approval

    Waterproof medical grade desktop ip67 touch panel pc with wide screen high resolution

    Feature
    This is a Aluminum Alloy IP68 waterproof PC, fanless, strong and tightly-sealed to sustain punishing temperatures, harsh impacts and intense equipment washdowns.


    1. 15.6" TFT LED, whole pc IP67/ IP68/IP69K waterproof


    2. Resolution 1920*1080


    3. Adopt 5 wire resistive touch screen, high precision, durable, anti-interference.


    4. Intel Core i3-6100U Dual Core 2.4GHz


    5. Multi I/O Interface optional, VGA/HDMI/LAN/USB/RS232


    6. DC12V~24V Input,(+9V~36V)wide voltage input optional


    7. Fully sealed and fanless design, full IP65 waterproof, Sealed I/O with cable set included.

    WPC-O156WBR
    SystemCPUIntel Core i3-6100U Dual Core 2.4GHz
    L2 Cache3MB
    ChipsetsIntel 6th Skylake-U SOC
    MemoryDDR4L 2133MHz 4GB, Up to 16GB
    Harddisk1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional
    GraphicsIntel HD Graphics 520
    NetworkIntel® i211 1000 Mbps port
    AudioRealtek ACL662 Audio controller
    Operation SystemWindows7 / 8 / 10, Linux, Unix, QNX
    I / OVGA1 x VGA / 1 x HD-MI ( Optional )
    LAN1 x LAN ( Optional )
    USB2 x USB2.0 / 2 x USB3.0 ( Optional )
    COM2 x RS232 ( Optional )
    Wireless NetworkWiFi + Bluetooth ( Optional )
    Other I/O Interface1 x Power Switch
    LCD PanelPanel Size15.6" Led
    Resolution1920 x 1080
    Aspect Ratio16:9
    Display Brightness600 cd/m2
    Contrast Ratio800:1
    Colors16.7M , 76% NTSC
    Response Time30 (Typ.)(Tr/Td) ms
    Viewing Angle80 / 80 / 80 / 65 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen Type5 wire resistive touch
    Transmittance>85%
    Response Time<5ms
    Surface Hardness≥3H
    Supply Voltage5.0V DC
    Touch Life≧ 1000W
    InstitutionalMaterialAluminum Alloy Shell
    ColorSilver / Black ( optional )
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP67 / IP68 / IP69K
    Product Dimension398 x 247 x 52 mm
    Cut-out Size/
    Packing Size460 x 180 x 400 mm
    Gross Weight7.0 KG
    Power and EnvironmentOperating Temperature-10~60°C
    Storage Temperature-20~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC 12V~24V / optional(+9V~36V)
    Power Consumption≦30W


    Medical Grade Desktop IP67 Panel PC Wide Touch Screen RoHS ApprovalMedical Grade Desktop IP67 Panel PC Wide Touch Screen RoHS ApprovalMedical Grade Desktop IP67 Panel PC Wide Touch Screen RoHS Approval

    Product Advantage

    1. Wide range: -20°C to 70°C working temperature range.


    2. Industrial LCD panel is wide viewing angle with high nits and true color.


    3. Motherboard is high performance and 7x24 continuous operation available.


    4. Heat sink in back case great for heat dissipation and beatiful appearance.


    5. Working voltage is wide range 12-24V, suitable for various industrial applications.


    6. Symmetric design can be utillized in portrait mode with style.



    Packing List

    WPC-O156WBR Waterproof Panel PC

    Waterproof VGA/RS232/LAN/USB/COM cables

    1x Utility DVD Driver

    1x Power Adaptor

    Our Advantage

    1. Experience

    QYT has more than 10 years rich experience in Industrial Computer/monitor filed.


    2. Wide products line

    7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.


    3. Customization functions

    It offers rich of interface to meet csutomers needs.


    4.Widely useage environment

    QYT computer/monitor which is widly used for kitchen,food industry, boat...etc
