    IP65 Embedded Stainless Steel Panel Pc 15 Inch J1900 4G RAM 64GB SSD TPM 2.0

    Ask Lasest Price
    Brand Name : QYT
    Model Number : PPC-J015SAC
    Certification : IP65 FCC CE ROHS
    Payment Terms : T/T , Paypal , L/C , D/A , D/P , Western Union , MoneyGram
    Supply Ability : 5000 Piece/Pieces per Month
    Delivery Time : 7 working days upon receive the payment
    • Product Details
    • Company Profile

    IP65 Embedded Stainless Steel Panel Pc 15 Inch J1900 4G RAM 64GB SSD TPM 2.0

    IP65 Embedded Touch Panel PC 15 inch J1900 4G RAM 64GB SSD TPM 2.0


    Feature
    1. 15" TFT LED, resolution 1024 x 768, Multi-Touch PCAP

    2. Intel Celeron Quad Core J1900 2.0GHz, industrial touch screen panel pc

    3. Multi ports for option: VGA/HD-MI/LAN/USB/COM

    4. Operating System: Win7/8/10/Linux/Ubuntu

    5. DC IN 9V~36V


    Specification

    PPC-J015SAC
    SystemCPUIntel Celeron Quad Core J1900 2.0GHz
    L2 Cache2MB
    ChipsetsIntel Bay Trail SOC
    MemoryDDR3L 1333MHz 4GB, Up to 8GB
    Harddisk1 x mSATA 64G SSD / ( 128G / 240G / 480G SSD ) optional
    GraphicsIntel HD Graphics
    NetworkIntel® I211-AT GbE LAN
    AudioRealtek ACL662 Audio controller
    TPMTPM 2.0
    Operation SystemWindows7 / 8 / 10, Linux, Unix, QNX
    I / OHDMI1 x H-DMI
    LAN2 x LAN
    USB3 x USB2.0 / 1 x USB3.0
    COM2 x RS-232 / 422 / 485
    Wireless Network4G / WiFi / Bluetooth ( Optional )
    Other I/O Interface1 x Power Switch
    LCD PanelPanel Size15" LED
    Resolution1024 x 768
    Aspect Ratio4:3
    Display Brightness350 cd/m2
    Contrast Ratio1000:1
    Backlight Lifetime50000 Hr (min.)
    Viewing Angle89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )
    Touch screenTouch Screen TypeMulti-Touch PCAP
    Transmittance>90%
    Response Time<5ms
    Surface Hardness≥7H
    Supply Voltage5.0V DC
    Touch Life≧ 3000W
    InstitutionalMaterialHigh-strength Al-alloy, support IP65
    ColorGray
    VESA MountingVESA: 100 x 100 mm
    Waterproof RateIP65
    Product Dimension361 x 285 x 60 mm
    Cut-out Size347 x 271 mm
    Packing Size460 x 180 x 400 mm
    Gross Weight7 KG
    Power and EnvironmentOperating Temperature-20~70°C
    Storage Temperature-30~80°C(-22~176°F)
    Relative Humidity5%~95%@40°C, non-condensing
    Vibration Range5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
    External Power SupplyAC 100 - 240V~50/60Hz,1.5A
    Working VoltageDC IN 9V~36V
    Power Consumption≦30W

    IP65 Embedded Stainless Steel Panel Pc 15 Inch J1900 4G RAM 64GB SSD TPM 2.0IP65 Embedded Stainless Steel Panel Pc 15 Inch J1900 4G RAM 64GB SSD TPM 2.0

    IP65 Embedded Stainless Steel Panel Pc 15 Inch J1900 4G RAM 64GB SSD TPM 2.0

    Application
    Ticket machine
    Out fare turnstile gates
    SMArt Lockers parcel locker
    On vessel
    Stereo garage
    Security monitoring
    Self serve kiosk
    Automatic pay station machine
    FAQ
    1. Q: Are you a manufacturer or trading company?
    A: We're a professional manufacturer with more than 10 years experience in industrial automation field.
    2. Q: Do you provide ODM/OEM or customized service?
    A: Yes,we support OEM&ODM service, let you get the products you want exactly.
    3. Q: What certifications do you have?
    A: There are CE, RoHS, FCC, IP68, IP69K certificates, etc,.
    4. Q: How long is the warranty?
    A: Our factory promised warranty is 1 year.
    5. Q:What is the lead time?
    A: 3 business days for samples order, 15 business days for mass production.
    6. Q: What is the MOQ?
    A: Sample testing is acceptable, the price is negotiable for bulk order.
